Centurion Specifications
SKU: 200103
Security |
|
|---|---|
| Security Rating | Non-UL |
| Door Type | Composite |
| Door Thickness | 4″ total with 1″ composite door front |
| Door Bolt Sides | 2-Sided Military Style locking bars |
| Body Steel Thickness | 14 Gauge |
| Total Body Thickness | .75″ |
| Lock | UL Listed, Sargent & Greenleaf™ |
| Lock Type | S&G UL Listed 6741 mechanical lock standard (NO key locking dial) with optional upgrade to NL electronic lock |
| Relocker Type | Fail-Safe™, Punch and Drill |
| Hardplate Lock Protection | Single RC63 hardplate |
| Bolt Locking Type | Direct Cam Drive |
| Bolt Diameter | 4″ Military Style Locking Bars |
| Bolt Protector Type | Single Hardplate |
Fire Protection |
|
|---|---|
| Fire Minutes | 30 Minutes |
| Fire Rating | 1200°/30 Minutes |
| Fire Temp | 1200° |
| Layers | 3 in ceiling and door, 1 on sides and doorjambs |
| Door Seal | Heat-Activated, Expanding Palusol™ |
Style & Functionality |
|
|---|---|
| Fabric Type | Gray Fabric |
| Upholstery | Fully Upholstered |
| Interior Lighting | optional |
| Door Panel | None; Accessory Door Panel Available |
Model Details by Size |
Centurion 12 | Centurion 18 | Centurion 24 |
|---|---|---|---|
| Bolt Count | 10 | 10 | 10 |
| Long-Gun Storage (PLEASE NOTE: Gun capacity may vary depending upon size of guns and scopes) |
12 | 18 | 24 |
| Interior Type | Gun Only | Gun Only or Dual Flex | Gun Only or Dual Flex |
| Dimensions H x W x D (Depth includes handle spokes installed; Add 1.5″ for optional outlet kit) | 59.5″ x 18.25″ x 18″ | 59.5″ x 24.25″ x 22″ | 59.5″ x 28.25″ x 22″ |
| MIN. DOORWAY WIDTH CLEARANCE TO DELIVER SAFE* | 18″ | 22″ | 22″ |
| Exterior Height | 59.5″ | 59.5″ | 59.5″ |
| Exterior Width | 18.25″ | 24.25″ | 28.25″ |
| Exterior Depth (Includes handle spokes installed; Add 1.5″ for optional outlet kit) | 18″ | 22″ | 22″ |
| FOOTPRINT (Width x Depth) | 18.25″ x 16″ | 24.25″ x 20″ | 28.25″ x 20″ |
| Exterior Cubic Feet (safe body only) | 10.1 | 16.7 | 19.4 |
| Interior Height | 56″ | 56″ | 56″ |
| Interior Width | 16.25″ | 22.25″ | 26.25″ |
| Interior Depth | 10″ | 13.5″ | 13.5″ |
| Interior Cubic Feet | 5.3 | 9.7 | 11.5 |
| Weight | 245 lbs. | 316 lbs. | 375 lbs. |
| Country of Origin | United States | United States | United States |
